Products Description
EV121WXM-N12, a high-quality display panel with a resolution of 1280x800 and a brightness of 500, making it suitable for a wide range of applications. This panel features a large display area of 261.12(W)×163.2(H) mm, contained within an attractive exterior measuring 277.7(W)×180.6(H)×9.2(D) mm.
With a contrast ratio of 1200:1 and a response time of only 30 ms, this display provides crystal-clear images and fast refresh rates for an enjoyable viewing experience. The EV121WXM-N12 is designed to last, with a working life of 50,000 hours, making it an ideal choice for long-term applications.
This display panel also features an LVDS interface with 20 pins, providing reliable and efficient communication. The EV121WXM-N12 is perfect for use in a variety of settings, including home entertainment systems, digital signage displays, and industrial control systems.
Overall, the EV121WXM-N12 is a top-of-the-line display panel that provides exceptional image quality and long-lasting performance. Its advanced features and versatile design make it the perfect choice for a wide range of applications.
Product Parameter
|
NO. |
Product name |
12.1 inch BOE LCD module EV121WXM-N12 |
|
1 |
Display type |
a-Si TFT-LCD, LCD module |
|
2 |
Screen Size |
12.1 inch |
|
3 |
Interface Type |
LVDS (1 ch, 6/8-bit) , 20 pins Connector |
|
4 |
Pixel Format |
1280(RGB)×800, WXGA 124PPI |
|
5 |
Luminance |
500 cd/m² (Typ.) |
|
6 |
Display Area |
261.12(W)×163.2(H) mm |
|
7 |
Operating Temperature |
-20 ~ 70 °C |
|
8 |
Storage Temperature |
-30 ~ 80 °C |
|
9 |
Contrast |
1200:1 (Typ.) (TM) |
|
10 |
Apparent dimension |
277.7(W)×180.6(H) ×9.2(D) mm |
|
11 |
Response time |
30 (Typ.)(Tr+Td) |
|
12 |
Supply voltage |
3.3V (Typ.) |
|
Reminder: For detailed information and quotation, please contact customer service to obtain.
FEATURE 01 0.5T Glass(Single) FEATURE 02 Normal Type FEATURE 03 6/ 8bits LVDS data input selection FEATURE 04 Thin and light weight FEATURE 05 High luminance and contrast ratio, low reflection and wide viewing angle FEATURE 06 RoHS complian
|
||
FAQ
Screen damage
The damaged part of the LCD is incomplete, damaged corners and edges are damaged, and the conductive layer is damaged.
Poor glass cracking
Y axis cutting, X axis cracks caused by a part of the protrusion or depression.
polarizer scratches, punctured
the polarizer is damaged or damaged by hard hands such as blades.
Packing Details
|
Box Type |
Pcs/Box |
Box Qty |
Package LWH(mm) |
G.W(kgs) |
Volume (m³) |
|
Carton |
15 |
1 |
375x280x290 |
N/A |
0.0305 |
|
Paiiet |
360 |
24 |
N/A |
N/A |
N/A |
