Detailed Specifications Table
| Parameter | Specification |
|---|---|
| Panel Type | a-Si TFT-LCD, IPS hard screen |
| Resolution | 800×1280 (10:16 portrait) |
| Active Area (A.A.) | 107.64 (H) × 172.22 (V) mm |
| Outline Dimensions | 114.8 (H) × 184.2 (V) × 2.25 (T) mm |
| Brightness | 800 cd/m² (Typ., customizable to 1000+ nits) |
| Contrast Ratio | 800:1 (Typ.) |
| Viewing Angle | 80/80/80/80 (L/R/U/D) – true all-view IPS |
| Response Time | ≤20ms |
| Display Colors | 16.7M (8-bit) |
| Backlight | WLED |
| Signal Interface | MIPI DSI, 31 pins |
| Touch Screen | In-cell CTP (multi-touch, high sensitivity) |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -30°C ~ +80°C |
| Power Consumption | ≤6W (typical) |
Typical Applications
Outdoor industrial instruments & kiosks
Marine & automotive displays
(vibration & salt-fog resistant)
Medical monitors
(high brightness + wide viewing angle)
POS & self-service terminals under strong ambient light
Key Features & Advantages
This 8 inch high brightness display is built for real-world demanding conditions. The 800 nits backlight combined with IPS technology means colors stay accurate and readable even in bright outdoor light – no more washed-out screens on sunny days. In-cell touch delivers thinner profile and better optical performance than traditional on-cell solutions, while the MIPI interface keeps wiring simple and power low for embedded ARM/RK/Android/Linux platforms.
Compared to standard panels, our 8 inch high brightness display offers superior sunlight readability, wider temperature range, and lower failure rates in harsh environments. Need even better performance? We routinely upgrade to 1000-1200 nits, add optical bonding for anti-reflection, or integrate anti-fingerprint/anti-glare coatings – all at factory-direct pricing.
MINGHUA DISPLAY CO., LTD -pioneers LCD and high brightness display solutions across the Greater Bay Area. Serving 20+ countries in Southeast Asia, Europe, and the Americas with seamless online-offline support, we deliver premium panels (0.9"–75") from top-tier brands. Our rugged LCDON industrial all-in-one PCs excel in waterproof, dustproof, shockproof, and extreme-temperature performance. From laptops to medical devices, smart homes to heavy machinery, we customize for your needs-creating unbeatable value with competitive quality and high-impact service. Partner with us today!
