Products Description

A 13.3-inch Screen HD with A-SI TFT-LCD technology equipped with WLED backlight, including LED driver backlight drive, no touch. As an AAS, normally black display, transmission LCD module product, 13.3 Inch Screen HD can provide 800:1 transmission contrast, and 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) viewing Angle, the best viewing Angle is full viewing Angle. Its response time is 14/11 (Typ.)(Tr/Td) ms. Thanks to the 6-bit grayscale signal per pixel, this product can display 262K colors and display color saturation of 100% (sRGB). In terms of backlight, this product uses a side entry light source with WLED light, and the service life of the light source is 10K hours, including LED driver. The 13.3-inch Screen FHD uses eDP (2 Lanes) signal interface, a total of 30 pins, is connected by terminals, and the drive screen voltage is 3.3V (Typ.). Its typical vertical refresh rate, Fv, is 60Hz. All parameters are entered by electronic engineers according to the specifications. We have tried our best to reduce errors, but we cannot guarantee that the parameters are completely correct. Please refer to the specification! Its operating temperature is -20 ~+ 70°C, storage temperature is -30 ~+80°C, and vibration resistance is 1.5G (14.7 m/s²). Based on it sRGB, white LED backlight, including LED driver, terminal flip, surface fog, eDP1.3, this model is recommended for notebook products.

How LCD displays work

LCD stands for liquid crystal display, which means it uses a layer of liquid crystals sandwiched between two polarized filters and a backlight. The liquid crystals can change their orientation and transparency when an electric current is applied, allowing different amounts of light to pass through and create pixels of various colors and brightness. LCD displays are popular because they are thin, lightweight, energy-efficient, and relatively inexpensive.

How LCD displays get damaged

LCD displays can be damaged by a variety of factors, including physical impacts, scratches, pressure, heat, moisture, dust, or faulty components. Common signs of LCD display damage may include cracks or breaks on the screen, dead or stuck pixels that show one color or no color at all, lines, spots, or blobs on the screen, flickering or fading of the backlight, distorted colors or contrast, blurry or ghost images, and no image or signal.

about us

Shenzhen Zhongchuangxiang Technology Co., Ltd. is a company specializing in the design, production and sales of LCD modules, OLED modules and their peripheral products. The main business includes TFT, IPS series screens, serial screens, LCD screens, FHD screens and HD screens, touch screens, etc., with sizes from 1.44 inches to 17.3 inches. We can meet the high satisfaction of customers through excellent supply chains such as Innolux, BOE, AUO, Hanyu Caijing, Sharp, etc. The company also has a high-quality technology research and development team, and continuously introduces products with advanced technology. Trusted and praised by customers.

The company's existing plant is nearly 1,500 square meters, with more than 80 front-line employees. The company has domestic first-class cutting machines, cleaning lines, COG, FOG, and other liquid crystal display module assembly production lines, with a monthly production capacity of more than 1,000K; the workshop implements a central The air conditioner is centrally controlled, the constant temperature is 25 degrees Celsius, the cleanliness is class 1000, and some parts are class 100. The environment is comfortable, no noise, no pollution.

FAQ

Q:Can you buy a replacement laptop screen?

A:Whether your laptop screen is damaged or developed a ghosting issue, you don't have to buy a new laptop. 9 out of 10 laptop screens can be replaced.

Q:Is 13.3 a small screen?

A:For many, the screen size may be a little small, again depending on the type of work you do. However, many users will connect their laptop to a full size external monitor, keyboard and mouse when they need desktop capabilities.

Q:Can I replace my laptop LCD with LED?

A:Yes, in many cases, you can replace a laptop's LCD screen with an LED screen, as long as the physical dimensions and connection interfaces are compatible. However, it's important to clarify a common misconception: LED screens are actually a type of LCD screen, but with a different backlighting technology.
