Complete Specifications Table
| Specification Category | Parameter | Details |
|---|---|---|
| Display Characteristics | ||
| Panel Size | Diagonal | 11.6 inches |
| Panel Type | Technology | a-Si TFT-LCD, Transmissive |
| Resolution | Pixels | 1920(RGB) × 1080, Full HD |
| Pixel Density | PPI | 190 PPI |
| Pixel Arrangement | Layout | RGB Vertical Stripe |
| Active Display Area | Dimensions | 256.32(W) × 144.18(H) mm |
| Overall Module Size | Dimensions | 273.5(W) × 166.5(H) × 11.5(D) mm |
| Viewable Area | Dimensions | 259.31(W) × 148.73(H) mm |
| Optical Performance | ||
| Surface Treatment | Coating | Hard Coating (anti-glare) |
| Brightness | Luminance | 1000 cd/m² (Typical) |
| Contrast Ratio | Dynamic Range | 900:1 (Typical) |
| Viewing Angle | Coverage | 88°/88°/88°/88° (L/R/U/D, CR≥10) |
| Display Mode | Technology | SFT, Normally Black, Transmissive |
| Viewing Direction | Optimal | Full viewing angle |
| Response Time | Speed | 25ms (Typical, Tr+Td) |
| Color Depth | Gamut | 16.7M colors, 70% NTSC |
| Backlight System | ||
| Light Source | Configuration | 9S6P WLED array |
| Backlight Lifespan | Durability | 50,000 hours (without driver) |
| Electrical & Interface | ||
| Refresh Rate | Frequency | 60Hz |
| Signal Interface | Type | LVDS (2 channel, 8-bit), 30-pin connector |
| Drive Voltage | Power | 3.3V (Typical) |
| Touch Panel | Standard | None (customizable upon request) |
| Environmental Specifications | ||
| Operating Temperature | Range | -20°C to +70°C |
| Storage Temperature | Range | -30°C to +85°C |
| Application Target | ||
| Primary Markets | Industries | Industrial, Outdoor High Brightness |
| Physical | ||
| Module Weight | Mass | TBD (Typically ~400-500g for similar modules) |
Key Features
Key Features That Make This 11.6 Inch High Brightness LCD Module Stand Out
1000 nits = actually readable in real sunlight
Regular laptop screens (300 nits) go black the second they see sun. Even 500-nit "bright" ones only work in shade. This 1000 nits display? Got them on city buses facing west in the afternoon - passengers can still read the next-stop info without squinting. That's the difference.
1920×1080 on 11.6" hits the sweet spot
190 PPI - text and icons are razor-sharp, but you're not wasting horsepower pushing 4K. Perfect for HMI panels, medical devices, vehicle info displays, or any embedded box. Drop 1080p content on it and it just works, no scaling weirdness.
88° viewing angle that actually means something
SFT panel (Super Fine TFT). Stand left, right, above, below - colors don't shift and contrast stays solid. I always do the side-by-side test with cheap TN panels; the TN washes out at 30°, this one still looks perfect at 88°.
-20°C to +70°C, no drama
Cold winter mornings in the Midwest? Starts instantly. Baking inside a tractor cab in July? Keeps running. We have these in agricultural machines in Iowa that see -15°C before dawn and 65°C by noon. Zero failures.
Hard-coated, matte surface - scratch-proof and zero glare
7H surface, keys don't scratch it. The matte finish kills reflections completely. I've stood two kiosks side-by-side in direct sun - one glossy, one with this coating. The glossy one was a mirror; this one you could read comfortably all day.
50,000-hour backlight - basically a 10-year part
24/7 would be 5+ years before it hits half brightness. Most customers run 12–16 hours/day, so real-world life is easily 10–12 years. We still have batches running after 4+ years with less than 10% drop.
outdoor digital signage at EV stations or bus stops-1000 nits display cuts through glare like butter.
Industrial HMIs in warehouses or manufacturing lines? It thrives there, delivering clear SCADA visuals even under fluorescent buzz or skylight spill.
Marine dashboards, agricultural equipment monitors, or even medical kiosks in bright clinics-anywhere ambient light is the enemy, this bright monitors steps up.
who choose us?
We get it-off-the-shelf rarely cuts it in B2B. That's why every high brightness LCD module from us starts with a chat: spill your project's industry, and our engineers craft a custom LCD scheme around your needs-be it bumping to 1200 nits, adding glove-touch, or optimizing for low power for your bright monitors.
Fast prototyping (2-4 weeks), volume pricing that scales with your order, and global shipping with full certs (RoHS, CE). It's all about making your buy the smartest one: top-shelf quality at reasonable rates, tailored just for you.
one-stop solution
professional team
high quality
FAQ
Q: What's the minimum order for this 11.6 inch high brightness LCD module?
A: Starts at 100 units for stock configs, but we flex for samples-hit us up for quotes.
Q: Can I get it with touch or higher brightness on this bright monitors?
A: Absolutely, customization is our jam. For outdoor industrial use, we can add PCAP touch or push to 1500 nits-our team builds schemes based on your field details.
Q: How does 1000 nits display hold up in direct sun?
A: Like a champ-it's sunlight-readable gold for most apps. Pair with anti-reflective coating for extreme glare, and you're set.
Q: Wide-temp range: real or hype?
A: Real as it gets-tested to -20~70°C operating. Perfect for unconditioned factories or vehicles.
Q: Lead time and pricing?
A: 4-6 weeks standard for this bright monitors; pricing drops with volume. Share your project specs for a custom quote that nails value.
