Description

Send Inquiry

Product Model

Product Model	Description
ZCX12848Z168-001N	UART series,6.8 inch screen,4.5V-28V (error ±0.2V),1280*480 ,ROHS, CE certification (EMI level: EN55022 ClassB standard) ,No touch
ZCX12848Z168-001C	UART series,6.8 inch screen,4.5V-28V (error ±0.2V),1280*480 ,ROHS, CE certification (EMI level: EN55022 ClassB standard),Capacitive touch

Products Description

The 6.8-inch serial display is an LCD module with high brightness and special installation flexibility, suitable for a variety of applications. We are a professional electronic screen manufacturer and supplier in China, specializing in providing high-quality customized services.

NO.	Product name	6.8 inch UART Display
1	Display type	TFT LCD screen
2	Screen Size	6.8 inch
3	Backlight life (average)	> 20,000 hours
4	Pixel Format	1280*480
5	Luminance	700(cd/m²)
6	Display Area	161.3mm×60.9mm
7	Operating Temperature	-20 ~+70 °C(Optional)
8	Storage Temperature	-30 ~ +80 °C(Optional)
9	Contrast	900:1
10	Voltage	4.5V-28V (error ±0.2V)
11	core processor	800MHz 32-bit dual-core processor
12	Dimensions	198.8mm×67.7mm×16.8mm
Reminder: For detailed information and quotation, please contact customer service to obtain.

Advantage

Ultra-High Brightness

Peaks at 700 cd/m², delivering crystal-clear visuals even under direct sunlight or intense ambient light-ideal for outdoor and high-illumination environments.

Crisp High Resolution

1280×480 resolution ensures sharp, detailed images and text, perfect for applications requiring rich visual information.

Versatile Orientation

Supports 0°/90°/180°/270° rotation, enabling seamless portrait or landscape mounting to fit any setup with ease.

Dual Communication Modes

Compatible with RS232 and TTL interfaces, offering flexible connectivity options for diverse systems and devices.

Application areas

Car Navigation & Infotainment Multi-angle mounting and 700 cd/m² sunlight-readable brightness make this display a perfect fit for in-vehicle GPS, rear-seat entertainment, and dashboard clusters.

Outdoor Digital Signage & Billboards High brightness + 1280×480 crisp resolution ensures vivid, legible content under direct sunlight-ideal for roadside ads, wayfinding kiosks, and large-format public displays.

Industrial HMI & Control Panels Flexible 0°/90°/180°/270° installation plus robust RS232/TTL interfaces enable seamless integration into factory automation, PLC dashboards, and real-time monitoring systems.

Public Information Displays Deliver instant updates-bus ETA, weather alerts, news tickers, or queue status-with sharp text and graphics that remain clear in any lighting condition.

Possible problems and solutions

Troubleshooting Communication Issues If communication fails, first verify the connection setup:

Confirm cable integrity and proper port insertion
Check protocol consistency and parameter matching (baud rate, data bits, etc.) between devices
If unresolved, inspect hardware interfaces or contact professional technical support

Brightness Adjustment Guide Adapt screen brightness to any environment using the built-in adjustment function-fine-tune manually to achieve optimal visibility and comfort under varying light conditions.

Installation Best Practices When selecting orientation, prioritize viewer position and ambient light direction to maximize image clarity and readability from the target perspective.

Thermal Management for Durability High-brightness mode (700 cd/m²) generates additional heat during extended use. Implement adequate ventilation or cooling (e.g., fans or heat sinks) to maintain long-term performance and reliability.

Software & Driver Compatibility Ensure connected systems have up-to-date drivers and compatible software to guarantee accurate content rendering and full display functionality.

about us

Shenzhen Zhongchuangxiang Technology Co., Ltd. is a diversified enterprise focusing on R&D, design, manufacturing and sales of integrated solutions. We provide customers with a full range of customer services, including pre-sales consultation, in-sales support and after-sales maintenance.

The company has first-class production facilities, including a thousand-level dust-free workshop covering an area of more than 1,500 square meters and equipped with five automated production lines with a monthly production capacity of up to 10,000 pieces. We have a high-quality staff team of more than 100 employees, ensuring high efficiency and quality of production.

Our advantage:

Integrated solution manufacturer: As a professional display and touch integrated solution manufacturer, we have more than fifteen years of rich experience, provide full follow-up of customer project development, and provide professional advice and guidance.

Comprehensive quality control: We strictly inspect all raw materials, use professional testing equipment to ensure product quality, and adopt constant temperature and humidity, aging and other reliability tests. The product qualification rate is as high as 99.8% or more.

High-quality raw materials: We select high-quality glass, backlight materials, driver chips, FPC, PCB boards and other raw materials to ensure the high performance and stability of the product.

We also accept customized services, customization process: ① via phone/webpage/email; ② confirm requirements; ③ provide solutions; ④ customer approval; ⑤ process tools; ⑥ confirm samples; ⑦ trial production; ⑧ mass production, ⑨ delivery Order, ⑩ after-sales service.

Our team understands the diverse needs of our customers and provides high-quality solutions according to the needs. We are committed to meeting our customers' expectations by ensuring that our products are sourced from trustworthy vendors and undergo stringent quality testing to deliver flawless products. As a professional electronic screen manufacturer and supplier in China, we provide high-quality customized services and wholeheartedly welcome you to purchase or wholesale high-end electronic screens at competitive prices.
