Parameter |
Specification |
|
Size |
15.6 inches |
|
Resolution |
1920 x 1080 (Full HD) |
|
Aspect Ratio |
16:9 |
|
Touch Type |
10-point Projected Capacitive (P-CAP) |
|
Luminance |
450 cd/m² |
|
Video Inputs |
HDMI, DisplayPort (DP), VGA |
|
Touch Interface |
USB (for multi-touch under Win 7/8/10) |
|
Power Input |
24 VDC |
|
Ingress Protection |
Front Panel IP66 |
|
Housing |
Die-cast aluminum chassis + aluminum alloy front bezel |
|
Mounting Options |
Panel mount, desktop, VESA arm, wall, rack |
|
Other Features |
Lockable I/O connectors, flat touchscreen surface |
Key Features & Benefits
This monitor packs everything you need for reliable 24/7 operation:
- Responsive 10-point P-CAP touch - smooth multi-touch even with gloves, perfect for operators who need quick, accurate inputs.
- High brightness & wide viewing - 450 nits keeps things clear in bright factory lighting, with excellent color and detail thanks to Full HD resolution.
- Rugged build for harsh environments - IP66 front panel blocks dust and water, aluminum chassis handles vibration and shocks, lockable connectors prevent accidental unplugging.
- Flexible connectivity - HDMI, DP, and VGA cover most industrial PCs and legacy systems.
- Easy installation - slim profile, multiple mounting ways (panel, VESA, desktop stand, etc.), so it fits into cabinets, arms, or walls without hassle.
- Long-term reliability - industrial-grade components mean fewer failures and lower maintenance costs over time.
Applications
Our Commitment – Personalized Service
We've shipped hundreds of these industrial touchscreen monitors to factories across different industries, and feedback is consistent: "It just keeps running." Many come back for repeat orders or expansions because the reliability pays off quickly.
We also provide test samples, detailed drawings, and long-term component support so you don't face sudden obsolescence.
We know B2B projects are complex, so we make it easy:
- Full customization - brightness upgrade, different interfaces, special enclosures - just share your industry and specs, our engineers design the best-fit solution at a reasonable price.
- Quick response - pre-sales technical advice within 24 hours.
- After-sales - 1-3 year warranty (extendable), fast troubleshooting, and global shipping support.
- No MOQ headaches - flexible for prototypes or small batches.
You're not buying a generic monitor; you're getting a partner who helps your project succeed.
FAQ
Q: How thick are the gloves that work with this P-CAP touch?
A: The 10-point projected capacitive (P-CAP) touch supports most standard industrial gloves (latex, nitrile, or thin rubber ones up to about 1-1.5mm thick). For thicker work gloves, we recommend testing a sample first - we can also tune sensitivity or suggest a customized version if your operators use heavy protective gear.
Q: What's the operating temperature range? Can it handle extreme cold or heat?
A: Standard models run reliably from 0°C to 50°C. For harsher environments (like outdoor or freezer applications), we offer wide-temperature customizations from -20°C to 70°C or even -40°C to 80°C using industrial-grade components. Just share your site's conditions - our engineers will match the right backlight and internals.
Q: Is the screen sunlight readable or suitable for bright factory lighting?
A: With 450 cd/m² brightness, it performs well in typical indoor industrial lighting and most well-lit factories. For direct sunlight or very bright areas, we can upgrade to 800–1000+ nits with optical bonding to cut glare and boost contrast. Anti-glare coatings are also available as a custom option.
Q: How long does this monitor usually last in 24/7 operation?
A: In real industrial use (with proper ventilation and basic maintenance), expect 50,000+ hours MTBF and 7–10 years of service life. The fanless design, high-quality LED backlight, and aluminum chassis help a lot - way longer than standard commercial displays.
